leadframe. Solderable per MIL-STD-202, Method 208

DS30759 Rev. 2 - 2 1 of 4 PDU540

PowerDI is a trademark of Diodes Incorporated.

www.diodes.com

Diodes Incorporated

PDU540

5A ULTRA-FAST RECOVERY RECTIFIER

PowerDI5

Features

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

Mechanical Data

Characteristic Symbol

Value

Unit

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

VRRM

VRWM

400 V

RMS Reverse Voltage

VR(RMS)

283 V

Average Rectified Output Current (See also figure 4)

Non-Repetitive Peak Forward Surge Current

8.3ms Single half sine-wave Superimposed on Rated Load

IFSM

125 A

NEW PRODUCT

Maximum Ratings

@ TA

= 25C unless otherwise specified

Characteristic Symbol Typ Max Unit

Thermal Resistance Junction to Soldering Point

RJS

3.0

C/W

Thermal Resistance Junction to Ambient Air (Note 2) TA

= 25C

RJA

C/W

Thermal Resistance Junction to Ambient Air (Note 3) TA

= 25C

RJA

C/W

Thermal Resistance Junction to Ambient Air (Note 4) TA

= 25C

RJA

C/W

Operating Temperature Range

-65 to +175 °C

Storage Temperature Range

TSTG

-65 to +175 °C

Notes: 1. RoHS revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see

EU Directive Annex Notes 5 and 7.

2. FR-4 PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com/datasheets/ap02001.pdf.

3. Polymide PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com/datasheets/ap02001.pdf.

4. Polymide PCB, 2 oz. Copper. Cathode pad dimensions 9.4mm x 7.2mm. Anode pad dimensions 2.7mm x 1.6mm.

Case: PowerDI5

Case Material: Molded Plastic, “Green” Molding

Compound. UL Flammability Classification Rating 94V-0

Moisture sensitivity: Level 1 per J-STD-020C

Terminals: Finish – Matte Tin annealed over Copper

Polarity: See Diagram on Page 4

Marking: See Page 3

Weight: 0.096 grams (approx.)

Glass Passivated Die Construction

Ultra-Fast Recovery Time for High Efficiency

High Maximum Junction Temperature

For Use in High Frequency Inverters, Free Wheeling, and

Polarity Protection Applications

High Forward Surge Current Capability

Lead Free Finish, RoHS Compliant (Note 1)

"Green" Molding Compound (No Br, Sb)

Qualified to AEC-Q101 Standards for High Reliability

Thermal Characteristics

TOP VIEW

BOTTOM VIEW
